Non Woven Zipper Bag Making Machine

The Non Woven Zipper Bag Making Machine manufactured by EZ TECH is compatible with 30-100g/㎡ non-woven fabric materials, and can be used with 200-800mm wide roll materials. The bag width can be adjusted from 100 to 800mm, and the bag height from 200 to 680mm. The production speed is stable at 40-80 pieces/minute. It supports 380V/220V universal voltage, and the entire machine is compact in size, measuring 8500×1370×1800mm. It can also be easily installed in small and medium-sized packaging factories, and is a practical model for the production of clothing, home textile, and daily necessities storage bags.

Equipment usage

Installation and Commissioning

After the Non Woven Zipper Bag Making Machine arrives, we will provide installation drawings and remote video guidance to help you quickly complete the assembly of the frame, power connection, and horizontal calibration. During the first trial run, the technicians will assist you online in completing the material feeding, zipper conveying, and heat sealing parameter adjustments to ensure that the feeding, laminating, and cutting processes are synchronized and stable.

Daily Production Operations

The equipment is equipped with an independent touch control operation panel. Parameters such as bag width, bag height, speed, heat sealing temperature, and zipper position can all be set with one click. During production, place the non-woven fabric roll and zipper roll on the corresponding material racks, and start the equipment to automatically complete material feeding, folding, zipper heat sealing, and cutting. The finished bags will automatically be output to the receiving platform without the need for continuous manual supervision.

Production Process Precautions

During the production process, regularly check the roll tension and deviation correction device to prevent raw material deviation; the heat sealing temperature needs to be adjusted based on the thickness of the non-woven fabric and the material of the zipper to prevent cases of unstable heat sealing or damaging the bag body; when encountering paper jams or fault alarms, first press the emergency stop button and then troubleshoot the problem; do not directly touch the running components with your hands.

MACHINE PARAMETERS

Equipment Maintenance

1. Daily Maintenance

After each production session, remove the loose non-woven fabric scraps from the surface of the Non Woven Zipper Bag Making Machine and the receiving platform, inspect the heat sealing knife and cutting knife for any remaining stains, and wipe them clean with a soft cloth; check the oil levels of all transmission parts, top up when insufficient; also clean the dust on the photoelectric deviation sensor surface to prevent it from affecting the positioning accuracy.

2. Regular Maintenance

Check the tension of the chain and belt once a week, adjust as necessary; add lubricating oil to the bearings and guide rails of the equipment monthly, check if the electrical circuits and terminal blocks are loose; inspect the flatness of the heat sealing knife and the temperature control module once a quarter to ensure precise temperature control and avoid affecting the heat sealing quality.

3. Common Fault Handling

Poor Heat Sealing: Check if the heat sealing temperature is too low, if the pressure is insufficient, or if there are stains on the heat sealing knife surface. Adjust the parameters and clean the knife surface to solve the problem.

Roll Material Deviation: Check if the deviation device is working properly, adjust the parameters of the tension controller, or reinstall the roll material to ensure alignment of the feeding.

Incorrect Cutting Size: Check the synchronization parameters of the servo motor, or calibrate the position of the photoelectric positioning sensor to ensure precise cutting positioning.

Customer Purchase Reviews

From Wang Boss of a clothing packaging factory in Jiaxing, Zhejiang Province:

We mainly produce non-woven fabric storage bags for women's clothing. Previously, we used semi-automated heat-sealing for zippers, which was inefficient and often resulted in crooked or de-laminated zippers. After switching to this EZ TECH Non Woven Zipper Bag Making Machine, we can complete the process with just one line. The zipper sealing is particularly strong, the dimensions are accurate, and the defect rate has been reduced to less than 1%. Now, the output of one shift is even higher than that of two days of manual work. It's so convenient.

From Ms. Li, a home textile packaging customer in Guangzhou, Guangdong Province:

After comparing several options, we finally chose this zipper bag making machine from EZ TECH. The main reason was that we were impressed by its ability to adapt to different thicknesses of non-woven fabric. Our company has both thin home textile storage bags and thicker bedding bags. This machine can handle all of them. The machine runs smoothly, the noise is low, and the technical support after-sales service is very good. They respond promptly when there are problems, and it's highly recommended.

From Mr. Zhang, the factory manager of a daily necessities packaging factory in Suzhou, Jiangsu Province:

At first, we were worried that this specialized model would be difficult to operate. But surprisingly, the workers learned it with videos for two days and could operate it easily. The touch panel of the equipment is very intuitive, the parameter settings are simple, and it also has adjustment space. We can make bags of different sizes without removing the molds. We just need to change the parameters. This is very friendly for our small factory with multiple orders. Now, during peak seasons, when we operate two lines, we can easily complete the orders.
